ERC-1967: 代理存储槽

event Upgraded(address indexed implementation);

event BeaconUpgraded(address indexed beacon);

event AdminChanged(address previousAdmin, address newAdmin);

/**
 * @dev This contract implements an upgradeable proxy. It is upgradeable because calls are delegated to an
 * implementation address that can be changed. This address is stored in storage in the location specified by
 * https://eips.ethereum.org/EIPS/eip-1967[EIP1967], so that it doesn't conflict with the storage layout of the
 * implementation behind the proxy.
 * @dev 此合约实现了一个可升级的代理。 它是可升级的，因为调用被委托给一个可以更改的实现地址。
 * @dev 此地址存储在 https://eips.ethereum.org/EIPS/eip-1967[EIP1967] 指定的位置的存储中，
 * @dev 以便它不会与代理后面实现的存储布局冲突。
 */
contract ERC1967Proxy is Proxy, ERC1967Upgrade {
    /**
     * @dev Initializes the upgradeable proxy with an initial implementation specified by `_logic`.
     * @dev 使用 `_logic` 指定的初始实现来初始化可升级代理。
     *
     * If `_data` is nonempty, it's used as data in a delegate call to `_logic`. This will typically be an encoded
     * function call, and allows initializing the storage of the proxy like a Solidity constructor.
     * 如果 `_data` 不为空，它将用作委托调用 `_logic` 中的数据。 这通常是一个编码的函数调用，
     * 并且允许像 Solidity 构造函数一样初始化代理的存储。
     */
    constructor(address _logic, bytes memory _data) payable {
        assert(_IMPLEMENTATION_SLOT == bytes32(uint256(keccak256("eip1967.proxy.implementation")) - 1));
        _upgradeToAndCall(_logic, _data, false);
    }

    /**
     * @dev Returns the current implementation address.
     * @dev 返回当前的实现地址。
     */
    function _implementation() internal view virtual override returns (address impl) {
        return ERC1967Upgrade._getImplementation();
    }
}

/**
 * @dev This abstract contract provides getters and event emitting update functions for
 * https://eips.ethereum.org/EIPS/eip-1967[EIP1967] slots.
 * @dev 这个抽象合约为 https://eips.ethereum.org/EIPS/eip-1967[EIP1967] 插槽提供了 getter 和事件发射更新函数。
 */
abstract contract ERC1967Upgrade {
    // This is the keccak-256 hash of "eip1967.proxy.rollback" subtracted by 1
    // 这是 "eip1967.proxy.rollback" 的 keccak-256 哈希值减 1
    bytes32 private constant _ROLLBACK_SLOT = 0x4910fdfa16fed3260ed0e7147f7cc6da11a60208b5b9406d12a635614ffd9143;

    /**
     * @dev Storage slot with the address of the current implementation.
     * This is the keccak-256 hash of "eip1967.proxy.implementation" subtracted by 1, and is
     * validated in the constructor.
     * @dev 具有当前实现地址的存储槽。
     * @dev 这是 "eip1967.proxy.implementation" 的 keccak-256 哈希值减 1，并在构造函数中进行验证。
     */
    bytes32 internal constant _IMPLEMENTATION_SLOT = 0x360894a13ba1a3210667c828492db98dca3e2076cc3735a920a3ca505d382bbc;

    /**
     * @dev Emitted when the implementation is upgraded.
     * @dev 当实现被升级时发出。
     */
    event Upgraded(address indexed implementation);

    /**
     * @dev Returns the current implementation address.
     * @dev 返回当前的实现地址。
     */
    function _getImplementation() internal view returns (address) {
        return StorageSlot.getAddressSlot(_IMPLEMENTATION_SLOT).value;
    }

    /**
     * @dev Stores a new address in the EIP1967 implementation slot.
     * @dev 在 EIP1967 实现槽中存储一个新地址。
     */
    function _setImplementation(address newImplementation) private {
        require(Address.isContract(newImplementation), "ERC1967: new implementation is not a contract");
        StorageSlot.getAddressSlot(_IMPLEMENTATION_SLOT).value = newImplementation;
    }

    /**
     * @dev Perform implementation upgrade
     * @dev 执行实现升级
     *
     * Emits an {Upgraded} event.
     * 发出 {Upgraded} 事件。
     */
    function _upgradeTo(address newImplementation) internal {
        _setImplementation(newImplementation);
        emit Upgraded(newImplementation);
    }

    /**
     * @dev Perform implementation upgrade with additional setup call.
     * @dev 使用额外的设置调用执行实现升级。
     *
     * Emits an {Upgraded} event.
     * 发出 {Upgraded} 事件。
     */
    function _upgradeToAndCall(
        address newImplementation,
        bytes memory data,
        bool forceCall
    ) internal {
        _upgradeTo(newImplementation);
        if (data.length > 0 || forceCall) {
            Address.functionDelegateCall(newImplementation, data);
        }
    }

    /**
     * @dev Perform implementation upgrade with security checks for UUPS proxies, and additional setup call.
     * @dev 对 UUPS 代理执行带有安全检查的实现升级，并带有额外的设置调用。
     *
     * Emits an {Upgraded} event.
     * 发出 {Upgraded} 事件。
     */
    function _upgradeToAndCallSecure(
        address newImplementation,
        bytes memory data,
        bool forceCall
    ) internal {
        address oldImplementation = _getImplementation();

        // Initial upgrade and setup call
        // 初始升级和设置调用
        _setImplementation(newImplementation);
        if (data.length > 0 || forceCall) {
            Address.functionDelegateCall(newImplementation, data);
        }

        // Perform rollback test if not already in progress
        // 如果尚未进行，则执行回滚测试
        StorageSlot.BooleanSlot storage rollbackTesting = StorageSlot.getBooleanSlot(_ROLLBACK_SLOT);
        if (!rollbackTesting.value) {
            // Trigger rollback using upgradeTo from the new implementation
            // 使用来自新实现的 upgradeTo 触发回滚
            rollbackTesting.value = true;
            Address.functionDelegateCall(
                newImplementation,
                abi.encodeWithSignature("upgradeTo(address)", oldImplementation)
            );
            rollbackTesting.value = false;
            // Check rollback was effective
            // 检查回滚是否有效
            require(oldImplementation == _getImplementation(), "ERC1967Upgrade: upgrade breaks further upgrades");
            // Finally reset to the new implementation and log the upgrade
            // 最后重置为新的实现并记录升级
            _upgradeTo(newImplementation);
        }
    }

    /**
     * @dev Storage slot with the admin of the contract.
     * This is the keccak-256 hash of "eip1967.proxy.admin" subtracted by 1, and is
     * validated in the constructor.
     * @dev 具有合约管理地址的存储槽。
     * @dev 这是 "eip1967.proxy.admin" 的 keccak-256 哈希值减 1，并在构造函数中进行验证。
     */
    bytes32 internal constant _ADMIN_SLOT = 0xb53127684a568b3173ae13b9f8a6016e243e63b6e8ee1178d6a717850b5d6103;

    /**
     * @dev Emitted when the admin account has changed.
     * @dev 当 admin 帐户已更改时发出。
     */
    event AdminChanged(address previousAdmin, address newAdmin);

    /**
     * @dev Returns the current admin.
     * @dev 返回当前的 admin。
     */
    function _getAdmin() internal view returns (address) {
        return StorageSlot.getAddressSlot(_ADMIN_SLOT).value;
    }

    /**
     * @dev Stores a new address in the EIP1967 admin slot.
     * @dev 在 EIP1967 admin 槽中存储一个新地址。
     */
    function _setAdmin(address newAdmin) private {
        require(newAdmin != address(0), "ERC1967: new admin is the zero address");
        StorageSlot.getAddressSlot(_ADMIN_SLOT).value = newAdmin;
    }

    /**
     * @dev Changes the admin of the proxy.
     * @dev 更改代理的 admin。
     *
     * Emits an {AdminChanged} event.
     * 发出 {AdminChanged} 事件。
     */
    function _changeAdmin(address newAdmin) internal {
        emit AdminChanged(_getAdmin(), newAdmin);
        _setAdmin(newAdmin);
    }

    /**
     * @dev The storage slot of the UpgradeableBeacon contract which defines the implementation for this proxy.
     * This is bytes32(uint256(keccak256('eip1967.proxy.beacon')) - 1)) and is validated in the constructor.
     * @dev UpgradeableBeacon 合约的存储槽，它定义了此代理的实现。
     * @dev 这是 bytes32(uint256(keccak256('eip1967.proxy.beacon')) - 1)) 并在构造函数中进行验证。
     */
    bytes32 internal constant _BEACON_SLOT = 0xa3f0ad74e5423aebfd80d3ef4346578335a9a72aeaee59ff6cb3582b35133d50;

    /**
     * @dev Emitted when the beacon is upgraded.
     * @dev 当信标升级时发出。
     */
    event BeaconUpgraded(address indexed beacon);

    /**
     * @dev Returns the current beacon.
     * @dev 返回当前的信标。
     */
    function _getBeacon() internal view returns (address) {
        return StorageSlot.getAddressSlot(_BEACON_SLOT).value;
    }

    /**
     * @dev Stores a new beacon in the EIP1967 beacon slot.
     * @dev 将新信标存储在 EIP1967 信标槽中。
     */
    function _setBeacon(address newBeacon) private {
        require(Address.isContract(newBeacon), "ERC1967: new beacon is not a contract");
        require(
            Address.isContract(IBeacon(newBeacon).implementation()),
            "ERC1967: beacon implementation is not a contract"
        );
        StorageSlot.getAddressSlot(_BEACON_SLOT).value = newBeacon;
    }

    /**
     * @dev Perform beacon upgrade with additional setup call. Note: This upgrades the address of the beacon, it does
     * not upgrade the implementation contained in the beacon (see {UpgradeableBeacon-_setImplementation} for that).
     * @dev 执行带有额外设置调用的信标升级。 注意：这会升级信标的地址，而不会升级信标中包含的实现（请参阅 {UpgradeableBeacon-_setImplementation}）。
     *
     * Emits a {BeaconUpgraded} event.
     * 发出 {BeaconUpgraded} 事件。
     */
    function _upgradeBeaconToAndCall(
        address newBeacon,
        bytes memory data,
        bool forceCall
    ) internal {
        _setBeacon(newBeacon);
        emit BeaconUpgraded(newBeacon);
        if (data.length > 0 || forceCall) {
            Address.functionDelegateCall(IBeacon(newBeacon).implementation(), data);
        }
    }
}

/**
 * @dev This abstract contract provides a fallback function that delegates all calls to another contract using the EVM
 * instruction `delegatecall`. We refer to the second contract as the _implementation_ behind the proxy, and it has to
 * be specified by overriding the virtual {_implementation} function.
 * @dev 这个抽象合约提供了一个回退函数，它使用 EVM 指令 `delegatecall` 将所有调用委托给另一个合约。
 * @dev 我们将代理后面的第二个合约称为_实现_，它必须通过覆盖虚拟的 {_implementation} 函数来指定。
 *
 * Additionally, delegation to the implementation can be triggered manually through the {_fallback} function, or to a
 * different contract through the {_delegate} function.
 * 此外，可以通过 {_fallback} 函数手动触发对实现的委托，或者通过 {_delegate} 函数触发对不同合约的委托。
 *
 * The success and return data of the delegated call will be returned back to the caller of the proxy.
 * 委托调用的成功和返回数据将返回给代理的调用者。
 */
abstract contract Proxy {
    /**
     * @dev Delegates the current call to `implementation`.
     * @dev 将当前调用委托给 `implementation`。
     *
     * This function does not return to its internal call site, it will return directly to the external caller.
     * 此函数不会返回到其内部调用站点，它将直接返回到外部调用者。
     */
    function _delegate(address implementation) internal virtual {
        assembly {
            // Copy msg.data. We take full control of memory in this inline assembly
            // block because it will not return to Solidity code. We overwrite the
            // Solidity scratch pad at memory position 0.
            // 复制 msg.data。 我们在这个内联汇编块中完全控制内存，因为它不会返回到 Solidity 代码。
            // 我们覆盖内存位置 0 处的 Solidity 草稿板。
            calldatacopy(0, 0, calldatasize())

            // Call the implementation.
            // out and outsize are 0 because we don't know the size yet.
            // 调用实现。
            // out 和 outsize 为 0，因为我们还不知道大小。
            let result := delegatecall(gas(), implementation, 0, calldatasize(), 0, 0)

            // Copy the returned data.
            // 复制返回的数据。
            returndatacopy(0, 0, returndatasize())

            switch result
            // delegatecall returns 0 on error.
            // delegatecall 在出错时返回 0。
            case 0 {
                revert(0, returndatasize())
            }
            default {
                return(0, returndatasize())
            }
        }
    }

    /**
     * @dev This is a virtual function that should be overridden so it returns the address to which the fallback function
     * and {_fallback} should delegate.
     * @dev 这是一个虚拟函数，应该被覆盖，以便它返回回退函数和 {_fallback} 应该委托到的地址。
     */
    function _implementation() internal view virtual returns (address);

    /**
     * @dev Delegates the current call to the address returned by `_implementation()`.
     * @dev 将当前调用委托给 `_implementation()` 返回的地址。
     *
     * This function does not return to its internal call site, it will return directly to the external caller.
     * 此函数不会返回到其内部调用站点，它将直接返回到外部调用者。
     */
    function _fallback() internal virtual {
        _beforeFallback();
        _delegate(_implementation());
    }

    /**
     * @dev Fallback function that delegates calls to the address returned by `_implementation()`. Will run if no other
     * function in the contract matches the call data.
     * @dev 回退函数，它将调用委托给 `_implementation()` 返回的地址。
     * @dev 如果合约中没有其他函数与调用数据匹配，则将运行。
     */
    fallback() external payable virtual {
        _fallback();
    }

    /**
     * @dev Fallback function that delegates calls to the address returned by `_implementation()`. Will run if call data
     * is empty.
     * @dev 回退函数，它将调用委托给 `_implementation()` 返回的地址。
     * @dev 如果调用数据为空，则将运行。
     */
    receive() external payable virtual {
        _fallback();
    }

    /**
     * @dev Hook that is called before falling back to the implementation. Can happen as part of a manual `_fallback`
     * call, or as part of the Solidity `fallback` or `receive` functions.
     * @dev 在回退到实现之前调用的 Hook。
     * @dev 可以作为手动 `_fallback` 调用的一部分发生，也可以作为 Solidity `fallback` 或 `receive` 函数的一部分发生。
     *
     * If overridden should call `super._beforeFallback()`.
     * 如果被覆盖，应该调用 `super._beforeFallback()`。
     */
    function _beforeFallback() internal virtual {}
}

/**
 * @dev Library for reading and writing primitive types to specific storage slots.
 * @dev 用于读取和写入原始类型到特定存储槽的库。
 *
 * Storage slots are often used to avoid storage conflict when dealing with upgradeable contracts.
 * This library helps with reading and writing to such slots without the need for inline assembly.
 * 存储槽通常用于避免在处理可升级合约时出现存储冲突。
 * 该库有助于读取和写入此类槽，而无需内联汇编。
 *
 * The functions in this library return Slot structs that contain a `value` member that can be used to read or write.
 * 此库中的函数返回包含 `value` 成员的 Slot 结构，该成员可用于读取或写入。
 */
library StorageSlot {
    struct AddressSlot {
        address value;
    }

    struct BooleanSlot {
        bool value;
    }

    struct Bytes32Slot {
        bytes32 value;
    }

    struct Uint256Slot {
        uint256 value;
    }

    /**
     * @dev Returns an `AddressSlot` with member `value` located at `slot`.
     * @dev 返回一个 `AddressSlot`，其成员 `value` 位于 `slot`。
     */
    function getAddressSlot(bytes32 slot) internal pure returns (AddressSlot storage r) {
        assembly {
            r.slot := slot
        }
    }

    /**
     * @dev Returns an `BooleanSlot` with member `value` located at `slot`.
     * @dev 返回一个 `BooleanSlot`，其成员 `value` 位于 `slot`。
     */
    function getBooleanSlot(bytes32 slot) internal pure returns (BooleanSlot storage r) {
        assembly {
            r.slot := slot
        }
    }

    /**
     * @dev Returns an `Bytes32Slot` with member `value` located at `slot`.
     * @dev 返回一个 `Bytes32Slot`，其成员 `value` 位于 `slot`。
     */
    function getBytes32Slot(bytes32 slot) internal pure returns (Bytes32Slot storage r) {
        assembly {
            r.slot := slot
        }
    }

    /**
     * @dev Returns an `Uint256Slot` with member `value` located at `slot`.
     * @dev 返回一个 `Uint256Slot`，其成员 `value` 位于 `slot`。
     */
    function getUint256Slot(bytes32 slot) internal pure returns (Uint256Slot storage r) {
        assembly {
            r.slot := slot
        }
    }
}
