ERC-5521: 可引用 NFT

pragma solidity ^0.8.4;

import "@openzeppelin/contracts/utils/introspection/IERC165.sol";

interface IERC_5521 is IERC165 {

    /// Logged when a node in the rNFT gets referred and changed.
    /// @notice Emitted when the `node` (i.e., an rNFT) is changed.
    // 当 rNFT 中的节点被引用和更改时记录。
    // @notice 当 `node`（即 rNFT）更改时发出。
    event UpdateNode(uint256 indexed tokenId,
                     address indexed owner,
                     address[] _address_referringList,
                     uint256[][] _tokenIds_referringList,
                     address[] _address_referredList,
                     uint256[][] _tokenIds_referredList
    );

    /// @notice set the referred list of an rNFT associated with different contract addresses and update the referring list of each one in the referred list. Checking the duplication of `addresses` and `tokenIds` is **RECOMMENDED**.
    // @notice 设置与不同合约地址关联的 rNFT 的被引用列表，并更新被引用列表中每个合约地址的引用列表。**建议**检查 `addresses` 和 `tokenIds` 是否重复。
    /// @param `tokenId` of rNFT being set. `addresses` of the contracts in which rNFTs with `tokenIds` being referred accordingly.
    // @param 要设置的 rNFT 的 `tokenId`。相应地，rNFT 与 `tokenIds` 被引用的合约的 `addresses`。
    /// @requirement
    // @requirement （要求）
    /// - the size of `addresses` **MUST** be the same as that of `tokenIds`;
    // - `addresses` 的大小**必须**与 `tokenIds` 的大小相同。
    /// - once the size of `tokenIds` is non-zero, the inner size **MUST** also be non-zero;
    // - 一旦 `tokenIds` 的大小非零，则内部大小**必须**也非零。
    /// - the `tokenId` **MUST** be unique within the same contract;
    // - `tokenId` 在同一合约中**必须**是唯一的。
    /// - the `tokenId` **MUST NOT** be the same as `tokenIds[i][j]` if `addresses[i]` is essentially `address(this)`.
    // - 如果 `addresses[i]` 本质上是 `address(this)`，则 `tokenId` **不得**与 `tokenIds[i][j]` 相同。
    function setNode(uint256 tokenId, address[] memory addresses, uint256[][] memory tokenIds) external;

    /// @notice get the referring list of an rNFT.
    // @notice 获取 rNFT 的引用列表。
    /// @param `tokenId` of the rNFT being focused, `_address` of contract address associated with the focused rNFT.
    // @param 关注的 rNFT 的 `tokenId`，与关注的 rNFT 关联的合约地址 `_address`。
    /// @return the referring mapping of the rNFT.
    // @return rNFT 的引用映射。
    function referringOf(address _address, uint256 tokenId) external view returns(address[] memory, uint256[][] memory);

    /// @notice get the referred list of an rNFT.
    // @notice 获取 rNFT 的被引用列表。
    /// @param `tokenId` of the rNFT being focused, `_address` of contract address associated with the focused rNFT.
    // @param 关注的 rNFT 的 `tokenId`，与关注的 rNFT 关联的合约地址 `_address`。
    /// @return the referred mapping of the rNFT.
    // @return rNFT 的被引用映射。
    function referredOf(address _address, uint256 tokenId) external view returns(address[] memory, uint256[][] memory);

    /// @notice get the timestamp of an rNFT when is being created.
    // @notice 获取 rNFT 创建时的时间戳。
    /// @param `tokenId` of the rNFT being focused, `_address` of contract address associated with the focused rNFT.
    // @param 关注的 rNFT 的 `tokenId`，与关注的 rNFT 关联的合约地址 `_address`。
    /// @return the timestamp of the rNFT when is being created with uint256 format.
    // @return rNFT 创建时的时间戳，格式为 uint256。
    function createdTimestampOf(address _address, uint256 tokenId) external view returns(uint256);

    /// @notice check supported interfaces, adhereing to ERC165.
    // @notice 检查支持的接口，遵守 ERC165。
    function supportsInterface(bytes4 interfaceId) external view returns (bool);
}

interface TargetContract is IERC165 {
    /// @notice set the referred list of an rNFT associated with external contract addresses.
    // @notice 设置与外部合约地址关联的 rNFT 的被引用列表。
    /// @param `_tokenIds` of rNFTs associated with the contract address `_address` being referred by the rNFT with `tokenId`.
    // @param 与合约地址 `_address` 关联的 rNFT 的 `_tokenIds`，这些 rNFT 被具有 `tokenId` 的 rNFT 引用。
    /// @requirement
    // @requirement （要求）
    /// - `_address` **MUST NOT** be the same as `address(this)` where `this` is executed by an external contract where `TargetContract` interface is implemented.
    // - `_address` **不得**与 `address(this)` 相同，其中 `this` 由实现了 `TargetContract` 接口的外部合约执行。
    function setNodeReferredExternal(address _address, uint256 tokenId, uint256[] memory _tokenIds) external;

    function referringOf(address _address, uint256 tokenId) external view returns(address[] memory, uint256[][] memory);

    function referredOf(address _address, uint256 tokenId) external view returns(address[] memory, uint256[][] memory);

    function createdTimestampOf(address _address, uint256 tokenId) external view returns(uint256);

    function supportsInterface(bytes4 interfaceId) external view returns (bool);
}

pragma solidity ^0.8.4;

import "@openzeppelin/contracts/token/ERC721/ERC721.sol";
import "./IERC_5521.sol";

contract ERC_5521 is ERC721, IERC_5521, TargetContract {

    struct Relationship {
        mapping (address => uint256[]) referring;
        mapping (address => uint256[]) referred;
        address[] referringKeys;
        address[] referredKeys;
        uint256 createdTimestamp; // unix timestamp when the rNFT is being created
        // rNFT 创建时的 Unix 时间戳

        // extensible parameters
        // 可扩展参数
        // ...
    }

    mapping (uint256 => Relationship) internal _relationship;
    address contractOwner = address(0);

    constructor(string memory name_, string memory symbol_) ERC721(name_, symbol_) {
        contractOwner = msg.sender;
    }

    function safeMint(uint256 tokenId, address[] memory addresses, uint256[][] memory _tokenIds) public {
        // require(msg.sender == contractOwner, "ERC_rNFT: Only contract owner can mint");
        // require(msg.sender == contractOwner, "ERC_rNFT: 只有合约所有者才能铸造");
        _safeMint(msg.sender, tokenId);
        setNode(tokenId, addresses, _tokenIds);
    }

    /// @notice set the referred list of an rNFT associated with different contract addresses and update the referring list of each one in the referred list
    // @notice 设置与不同合约地址关联的 rNFT 的被引用列表，并更新被引用列表中每个合约地址的引用列表
    /// @param tokenIds array of rNFTs, recommended to check duplication at the caller's end
    // @param tokenIds rNFT 数组，建议在调用者端检查重复项
    function setNode(uint256 tokenId, address[] memory addresses, uint256[][] memory tokenIds) public virtual override {
        require(
            addresses.length == tokenIds.length,
            "Addresses and TokenID arrays must have the same length"
            // "地址和 TokenID 数组的长度必须相同"
        );
        for (uint i = 0; i < tokenIds.length; i++) {
            if (tokenIds[i].length == 0) { revert("ERC_5521: the referring list cannot be empty"); }
            // if (tokenIds[i].length == 0) { revert("ERC_5521: 引用列表不能为空"); }
        }
        setNodeReferring(addresses, tokenId, tokenIds);
        setNodeReferred(addresses, tokenId, tokenIds);
    }

    /// @notice set the referring list of an rNFT associated with different contract addresses
    // @notice 设置与不同合约地址关联的 rNFT 的引用列表
    /// @param _tokenIds array of rNFTs associated with addresses, recommended to check duplication at the caller's end
    // @param _tokenIds 与地址关联的 rNFT 数组，建议在调用者端检查重复项
    function setNodeReferring(address[] memory addresses, uint256 tokenId, uint256[][] memory _tokenIds) private {
        require(_isApprovedOrOwner(msg.sender, tokenId), "ERC_5521: transfer caller is not owner nor approved");
        // require(_isApprovedOrOwner(msg.sender, tokenId), "ERC_5521: 转移调用者不是所有者，也没有获得批准");

        Relationship storage relationship = _relationship[tokenId];

        for (uint i = 0; i < addresses.length; i++) {
            if (relationship.referring[addresses[i]].length == 0) { relationship.referringKeys.push(addresses[i]); } // Add the address if it's a new entry
            // if (relationship.referring[addresses[i]].length == 0) { relationship.referringKeys.push(addresses[i]); } // 如果是新条目，则添加地址
            relationship.referring[addresses[i]] = _tokenIds[i];
        }

        relationship.createdTimestamp = block.timestamp;
        emitEvents(tokenId, msg.sender);
    }

    /// @notice set the referred list of an rNFT associated with different contract addresses
    // @notice 设置与不同合约地址关联的 rNFT 的被引用列表
    /// @param _tokenIds array of rNFTs associated with addresses, recommended to check duplication at the caller's end
    // @param _tokenIds 与地址关联的 rNFT 数组，建议在调用者端检查重复项
    function setNodeReferred(address[] memory addresses, uint256 tokenId, uint256[][] memory _tokenIds) private {
        for (uint i = 0; i < addresses.length; i++) {
            if (addresses[i] == address(this)) {
                for (uint j = 0; j < _tokenIds[i].length; j++) {
                    Relationship storage relationship = _relationship[_tokenIds[i][j]];
                    if (relationship.referred[addresses[i]].length == 0) { relationship.referredKeys.push(addresses[i]); } // Add the address if it's a new entry
                    // if (relationship.referred[addresses[i]].length == 0) { relationship.referredKeys.push(addresses[i]); } // 如果是新条目，则添加地址

                    require(tokenId != _tokenIds[i][j], "ERC_5521: self-reference not allowed");
                    // require(tokenId != _tokenIds[i][j], "ERC_5521: 不允许自引用");
                    if (relationship.createdTimestamp >= block.timestamp) { revert("ERC_5521: the referred rNFT needs to be a predecessor"); } // Make sure the reference complies with the timing sequence
                    // if (relationship.createdTimestamp >= block.timestamp) { revert("ERC_5521: 被引用的 rNFT 需要是一个前任"); } // 确保引用符合时序

                    relationship.referred[address(this)].push(tokenId);
                    emitEvents(_tokenIds[i][j], ownerOf(_tokenIds[i][j]));
                }
            } else {
                TargetContract targetContractInstance = TargetContract(addresses[i]);
                bool isSupports = targetContractInstance.supportsInterface(type(TargetContract).interfaceId);
                if (isSupports) {
                    // The target contract supports the interface, safe to call functions of the interface.
                    // 目标合约支持该接口，可以安全地调用该接口的函数。
                    targetContractInstance.setNodeReferredExternal(address(this), tokenId, _tokenIds[i]);
                }
            }
        }
    }

    /// @notice set the referred list of an rNFT associated with different contract addresses
    // @notice 设置与不同合约地址关联的 rNFT 的被引用列表
    /// @param _tokenIds array of rNFTs associated with addresses, recommended to check duplication at the caller's end
    // @param _tokenIds 与地址关联的 rNFT 数组，建议在调用者端检查重复项
    function setNodeReferredExternal(address _address, uint256 tokenId, uint256[] memory _tokenIds) external {
        for (uint i = 0; i < _tokenIds.length; i++) {
            Relationship storage relationship = _relationship[_tokenIds[i]];
            if (relationship.referred[_address].length == 0) { relationship.referredKeys.push(_address); } // Add the address if it's a new entry
            // if (relationship.referred[_address].length == 0) { relationship.referredKeys.push(_address); } // 如果是新条目，则添加地址

            require(_address != address(this), "ERC_5521: this must be an external contract address");
            // require(_address != address(this), "ERC_5521: 这必须是一个外部合约地址");
            if (relationship.createdTimestamp >= block.timestamp) { revert("ERC_5521: the referred rNFT needs to be a predecessor"); } // Make sure the reference complies with the timing sequence
            // if (relationship.createdTimestamp >= block.timestamp) { revert("ERC_5521: 被引用的 rNFT 需要是一个前任"); } // 确保引用符合时序

            relationship.referred[_address].push(tokenId);
            emitEvents(_tokenIds[i], ownerOf(_tokenIds[i]));
        }
    }

    /// @notice Get the referring list of an rNFT
    // @notice 获取 rNFT 的引用列表
    /// @param tokenId The considered rNFT, _address The corresponding contract address
    // @param tokenId 要考虑的 rNFT，_address 对应的合约地址
    /// @return The referring mapping of an rNFT
    // @return rNFT 的引用映射
    function referringOf(address _address, uint256 tokenId) external view virtual override(IERC_5521, TargetContract) returns (address[] memory, uint256[][] memory) {
        address[] memory _referringKeys;
        uint256[][] memory _referringValues;

        if (_address == address(this)) {
            require(_exists(tokenId), "ERC_5521: token ID not existed");
            // require(_exists(tokenId), "ERC_5521: Token ID 不存在");
            (_referringKeys, _referringValues) = convertMap(tokenId, true);
        } else {
            TargetContract targetContractInstance = TargetContract(_address);
            require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: target contract not supported");
            // require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: 目标合约不支持");
            (_referringKeys, _referringValues) = targetContractInstance.referringOf(_address, tokenId);
        }
        return (_referringKeys, _referringValues);
    }

    /// @notice Get the referred list of an rNFT
    // @notice 获取 rNFT 的被引用列表
    /// @param tokenId The considered rNFT, _address The corresponding contract address
    // @param tokenId 要考虑的 rNFT，_address 对应的合约地址
    /// @return The referred mapping of an rNFT
    // @return rNFT 的被引用映射
    function referredOf(address _address, uint256 tokenId) external view virtual override(IERC_5521, TargetContract) returns (address[] memory, uint256[][] memory) {
        address[] memory _referredKeys;
        uint256[][] memory _referredValues;

        if (_address == address(this)) {
            require(_exists(tokenId), "ERC_5521: token ID not existed");
            // require(_exists(tokenId), "ERC_5521: Token ID 不存在");
            (_referredKeys, _referredValues) = convertMap(tokenId, false);
        } else {
            TargetContract targetContractInstance = TargetContract(_address);
            require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: target contract not supported");
            // require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: 目标合约不支持");
            (_referredKeys, _referredValues) = targetContractInstance.referredOf(_address, tokenId);
        }
        return (_referredKeys, _referredValues);
    }

    /// @notice Get the timestamp of an rNFT when is being created.
    // @notice 获取 rNFT 创建时的时间戳。
    /// @param `tokenId` of the rNFT being focused, `_address` of contract address associated with the focused rNFT.
    // @param 关注的 rNFT 的 `tokenId`，与关注的 rNFT 关联的合约地址 `_address`。
    /// @return The timestamp of the rNFT when is being created with uint256 format.
    // @return rNFT 创建时的时间戳，格式为 uint256。
    function createdTimestampOf(address _address, uint256 tokenId) external view returns(uint256) {
        uint256 memory createdTimestamp;

        if (_address == address(this)) {
            require(_exists(tokenId), "ERC_5521: token ID not existed");
            // require(_exists(tokenId), "ERC_5521: Token ID 不存在");
            Relationship storage relationship = _relationship[tokenId];
            createdTimestamp = relationship.createdTimestamp;
        } else {
            TargetContract targetContractInstance = TargetContract(_address);
            require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: target contract not supported");
            // require(targetContractInstance.supportsInterface(type(TargetContract).interfaceId), "ERC_5521: 目标合约不支持");
            createdTimestamp = targetContractInstance.createdTimestampOf(_address, tokenId);
        }
        return createdTimestamp;
    }

    /// @dev See {IERC165-supportsInterface}.
    // @dev 参见 {IERC165-supportsInterface}。
    function supportsInterface(bytes4 interfaceId) public view virtual override (ERC721, IERC_5521, TargetContract) returns (bool) {
        return interfaceId == type(IERC_5521).interfaceId
            || interfaceId == type(TargetContract).interfaceId
            || super.supportsInterface(interfaceId);
    }

    // @notice Emit an event of UpdateNode
    // @notice 触发一个 UpdateNode 事件
    function emitEvents(uint256 tokenId, address sender) private {
        (address[] memory _referringKeys, uint256[][] memory _referringValues) = convertMap(tokenId, true);
        (address[] memory _referredKeys, uint256[][] memory _referredValues) = convertMap(tokenId, false);

        emit UpdateNode(tokenId, sender, _referringKeys, _referringValues, _referredKeys, _referredValues);
    }

    // @notice Convert a specific `local` token mapping to a key array and a value array
    // @notice 将特定的“本地”Token 映射转换为键数组和值数组
    function convertMap(uint256 tokenId, bool isReferring) private view returns (address[] memory, uint256[][] memory) {
        Relationship storage relationship = _relationship[tokenId];

        address[] memory returnKeys;
        uint256[][] memory returnValues;

        if (isReferring) {
            returnKeys = relationship.referringKeys;
            returnValues = new uint256[][](returnKeys.length);
            for (uint i = 0; i < returnKeys.length; i++) {
                returnValues[i] = relationship.referring[returnKeys[i]];
            }
        } else {
            returnKeys = relationship.referredKeys;
            returnValues = new uint256[][](returnKeys.length);
            for (uint i = 0; i < returnKeys.length; i++) {
                returnValues[i] = relationship.referred[returnKeys[i]];
            }
        }
        return (returnKeys, returnValues);
    }
}
