ERC-7812: ZK 身份注册表

pragma solidity ^0.8.0;

/**
 * @notice Evidence DB interface for Sparse Merkle Tree based statements database.
 * @notice 基于稀疏 Merkle 树的声明数据库的证据数据库接口。
 */
interface IEvidenceDB {
    /**
     * @notice Represents the proof of a node's inclusion/exclusion in the tree.
     * @notice 表示树中节点包含/排除的证明。
     * @param root The root hash of the Merkle tree.
     * @param siblings An array of sibling hashes can be used to get the Merkle Root.
     * @param existence Indicates the presence (true) or absence (false) of the node.
     * @param key The key associated with the node.
     * @param value The value associated with the node.
     * @param auxExistence Indicates the presence (true) or absence (false) of an auxiliary node.
     * @param auxKey The key of the auxiliary node.
     * @param auxValue The value of the auxiliary node.
     */
    struct Proof {
        bytes32 root;
        bytes32[] siblings;
        bool existence;
        bytes32 key;
        bytes32 value;
        bool auxExistence;
        bytes32 auxKey;
        bytes32 auxValue;
    }

    /**
     * @notice Adds the new element to the tree.
     * @notice 将新元素添加到树中。
     */
    function add(bytes32 key, bytes32 value) external;

    /**
     * @notice Removes the element from the tree.
     * @notice 从树中移除元素。
     */
    function remove(bytes32 key) external;

    /**
     * @notice Updates the element in the tree.
     * @notice 更新树中的元素。
     */
    function update(bytes32 key, bytes32 newValue) external;

    /**
     * @notice Gets the SMT root.
     * @notice 获取 SMT 根。
     * SHOULD NOT be used on-chain due to roots frontrunning.
     * 由于根抢跑，不应在链上使用。
     */
    function getRoot() external view returns (bytes32);

    /**
     * @notice Gets the number of nodes in the tree.
     * @notice 获取树中节点的数量。
     */
    function getSize() external view returns (uint256);

    /**
     * @notice Gets the max tree height (number of branches in the Merkle proof)
     * @notice 获取最大树高（Merkle 证明中的分支数）
     */
    function getMaxHeight() external view returns (uint256);

    /**
     * @notice Gets Merkle inclusion/exclusion proof of the element.
     * @notice 获取元素的 Merkle 包含/排除证明。
     */
    function getProof(bytes32 key) external view returns (Proof memory);

    /**
     * @notice Gets the element value by its key.
     * @notice 通过键获取元素值。
     */
    function getValue(bytes32 key) external view returns (bytes32);
}

pragma solidity ^0.8.0;

/**
 * @notice Common Evidence Registry interface.
 * @notice 通用证据注册表接口。
 */
interface IEvidenceRegistry {
    /**
     * @notice MUST be emitted whenever the Merkle root is updated.
     * @notice 只要 Merkle 根被更新，就必须发出。
     */
    event RootUpdated(bytes32 indexed prev, bytes32 indexed curr);

    /**
     * @notice Adds the new statement to the DB.
     * @notice 将新声明添加到数据库。
     */
    function addStatement(bytes32 key, bytes32 value) external;

    /**
     * @notice Removes the statement from the DB.
     * @notice 从数据库中移除声明。
     */
    function removeStatement(bytes32 key) external;

    /**
     * @notice Updates the statement in the DB.
     * @notice 更新数据库中的声明。
     */
    function updateStatement(bytes32 key, bytes32 newValue) external;

    /**
     * @notice Retrieves historical DB roots creation timestamps.
     * @notice 检索历史数据库根创建时间戳。
     * Latest root MUST return `block.timestamp`.
     * 最新根必须返回 `block.timestamp`。
     * Non-existent root MUST return `0`.
     * 不存在的根必须返回 `0`。
     */
    function getRootTimestamp(bytes32 root) external view returns (uint256);

    /**
     * @notice Builds and returns the isolated key for `source` and given `key`.
     * @notice 为 `source` 和给定的 `key` 构建并返回隔离的密钥。
     */
    function getIsolatedKey(address source, bytes32 key) external view returns (bytes32);
}

bytes32 isolatedKey = hash(msg.sender, key)

// SPDX-License-Identifier: CC0-1.0
pragma solidity ^0.8.21;

import {Initializable} from "@openzeppelin/contracts/proxy/utils/Initializable.sol";

import {IEvidenceDB} from "./interfaces/IEvidenceDB.sol";

import {SparseMerkleTree} from "./libraries/SparseMerkleTree.sol";
import {PoseidonUnit2L, PoseidonUnit3L} from "./libraries/Poseidon.sol";

contract EvidenceDB is IEvidenceDB, Initializable {
    using SparseMerkleTree for SparseMerkleTree.SMT;

    address private _evidenceRegistry;

    SparseMerkleTree.SMT private _tree;

    modifier onlyEvidenceRegistry() {
        _requireEvidenceRegistry();
        _;
    }

    function __EvidenceDB_init(address evidenceRegistry_, uint32 maxDepth_) external initializer {
        _evidenceRegistry = evidenceRegistry_;

        _tree.initialize(maxDepth_);

        _tree.setHashers(_hash2, _hash3);
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function add(bytes32 key_, bytes32 value_) external onlyEvidenceRegistry {
        _tree.add(key_, value_);
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function remove(bytes32 key_) external onlyEvidenceRegistry {
        _tree.remove(key_);
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function update(bytes32 key_, bytes32 newValue_) external onlyEvidenceRegistry {
        _tree.update(key_, newValue_);
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function getRoot() external view returns (bytes32) {
        return _tree.getRoot();
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function getSize() external view returns (uint256) {
        return _tree.getNodesCount();
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function getMaxHeight() external view returns (uint256) {
        return _tree.getMaxDepth();
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function getProof(bytes32 key_) external view returns (Proof memory) {
        return _tree.getProof(key_);
    }

    /**
     * @inheritdoc IEvidenceDB
     */
    function getValue(bytes32 key_) external view returns (bytes32) {
        return _tree.getNodeByKey(key_).value;
    }

    /**
     * @notice Returns the address of the Evidence Registry.
     * @notice 返回证据注册表的地址。
     */
    function getEvidenceRegistry() external view returns (address) {
        return _evidenceRegistry;
    }

    function _requireEvidenceRegistry() private view {
        if (_evidenceRegistry != msg.sender) {
            revert NotFromEvidenceRegistry(msg.sender);
        }
    }

    function _hash2(bytes32 element1_, bytes32 element2_) private pure returns (bytes32) {
        return PoseidonUnit2L.poseidon([element1_, element2_]);
    }

    function _hash3(
        bytes32 element1_,
        bytes32 element2_,
        bytes32 element3_
    ) private pure returns (bytes32) {
        return PoseidonUnit3L.poseidon([element1_, element2_, element3_]);
    }
}

// SPDX-License-Identifier: CC0-1.0
pragma solidity ^0.8.21;

import {Initializable} from "@openzeppelin/contracts/proxy/utils/Initializable.sol";

import {IEvidenceDB} from "./interfaces/IEvidenceDB.sol";
import {IEvidenceRegistry} from "./interfaces/IEvidenceRegistry.sol";

import {PoseidonUnit2L} from "./libraries/Poseidon.sol";

contract EvidenceRegistry is IEvidenceRegistry, Initializable {
    uint256 public constant BABY_JUB_JUB_PRIME_FIELD =
        21888242871839275222246405745257275088548364400416034343698204186575808495617;

    IEvidenceDB private _evidenceDB;

    mapping(bytes32 => uint256) private _rootTimestamps;

    modifier onlyInPrimeField(bytes32 key) {
        _requireInPrimeField(key);
        _;
    }

    modifier onRootUpdate() {
        bytes32 prevRoot_ = _evidenceDB.getRoot();
        _rootTimestamps[prevRoot_] = block.timestamp;
        _;
        emit RootUpdated(prevRoot_, _evidenceDB.getRoot());
    }

    function __EvidenceRegistry_init(address evidenceDB_) external initializer {
        _evidenceDB = IEvidenceDB(evidenceDB_);
    }

    /**
     * @inheritdoc IEvidenceRegistry
     */
    function addStatement(
        bytes32 key_,
        bytes32 value_
    ) external onlyInPrimeField(key_) onlyInPrimeField(value_) onRootUpdate {
        bytes32 isolatedKey_ = getIsolatedKey(msg.sender, key_);

        if (_evidenceDB.getValue(isolatedKey_) != bytes32(0)) {
            revert KeyAlreadyExists(key_);
        }

        _evidenceDB.add(isolatedKey_, value_);
    }

    /**
     * @inheritdoc IEvidenceRegistry
     */
    function removeStatement(bytes32 key_) external onlyInPrimeField(key_) onRootUpdate {
        bytes32 isolatedKey_ = getIsolatedKey(msg.sender, key_);

        if (_evidenceDB.getValue(isolatedKey_) == bytes32(0)) {
            revert KeyDoesNotExist(key_);
        }

        _evidenceDB.remove(isolatedKey_);
    }

    /**
     * @inheritdoc IEvidenceRegistry
     */
    function updateStatement(
        bytes32 key_,
        bytes32 newValue_
    ) external onlyInPrimeField(key_) onlyInPrimeField(newValue_) onRootUpdate {
        bytes32 isolatedKey_ = getIsolatedKey(msg.sender, key_);

        if (_evidenceDB.getValue(isolatedKey_) == bytes32(0)) {
            revert KeyDoesNotExist(key_);
        }

        _evidenceDB.update(isolatedKey_, newValue_);
    }

    /**
     * @inheritdoc IEvidenceRegistry
     */
    function getRootTimestamp(bytes32 root_) external view returns (uint256) {
        if (root_ == bytes32(0)) {
            return 0;
        }

        if (root_ == _evidenceDB.getRoot()) {
            return block.timestamp;
        }

        return _rootTimestamps[root_];
    }

    /**
     * @inheritdoc IEvidenceRegistry
     */
    function getIsolatedKey(address source_ bytes32 key_) public pure returns (bytes32) {
        return PoseidonUnit2L.poseidon([bytes32(uint256(uint160(source_))), key_]);
    }

    function getEvidenceDB() external view returns (address) {
        return address(_evidenceDB);
    }

    function _requireInPrimeField(bytes32 key_) private pure {
        if (uint256(key_) >= BABY_JUB_JUB_PRIME_FIELD) {
            revert NumberNotInPrimeField(key_);
        }
    }
}

// LICENSE: CC0-1.0
pragma circom 2.1.9;

include "SparseMerkleTree.circom";

template BuildIsolatedKey() {
    signal output isolatedKey;

    signal input address;
    signal input key;

    component hasher = Poseidon(2);
    hasher.inputs[0] <== address;
    hasher.inputs[1] <== key;

    hasher.out ==> isolatedKey;
}

template EvidenceRegistrySMT(levels) {
    // Public Inputs
    // 公共输入
    signal input root;

    // Private Inputs
    // 私有输入
    signal input address;
    signal input key;

    signal input value;

    signal input siblings[levels];

    signal input auxKey;
    signal input auxValue;
    signal input auxIsEmpty;

    signal input isExclusion;

    // Build isolated key
    // 构建隔离密钥
    component isolatedKey = BuildIsolatedKey();
    isolatedKey.address <== address;
    isolatedKey.key <== key;

    // Verify Sparse Merkle Tree Proof
    // 验证稀疏 Merkle 树证明
    component smtVerifier = SparseMerkleTree(levels);
    smtVerifier.siblings <== siblings;

    smtVerifier.key <== isolatedKey.isolatedKey;
    smtVerifier.value <== value;

    smtVerifier.auxKey <== auxKey;
    smtVerifier.auxValue <== auxValue;
    smtVerifier.auxIsEmpty <== auxIsEmpty;

    smtVerifier.isExclusion <== isExclusion;

    smtVerifier.root <== root;
}

component main {public [root]} = EvidenceRegistrySMT(80);
